Creating entities ​

Creating an entity is fast — pick a name, declare initial columns, save. Most of the work is figuring out the right shape before you click Create.

This page covers the UI flow and the decisions worth making upfront.

Where to create ​

Settings → Mapping → Entities. The page lists every entity in the current project. Click Create entity to open the new-entity form.

You'll be asked for:

  • A name. Free text.
  • An initial column list. Free text per column; the order is what shows in the record view.

When you save, the entity appears in the list with zero records. Add columns and rows after creation as needed.

Naming the entity ​

Names are user-facing — they show up in definitions ("target entity: Vendors") and in the record-view UI. Pick something readable.

Common patterns:

  • Plural-noun for collections. Vendors, Departments, Approvers. Reads naturally.
  • Specific descriptors for related tables. Header Products, Item Products. Distinguishes per-document-level from per-line-item lookups.
  • Domain-specific names if you have multiple subsidiaries. Polish Vendors, German Vendors — though discriminator-pattern entities (see below) often work better for multi-tenant cases.

Don't agonize. Entities are renameable; the system uses references, not names, internally.

Picking initial columns ​

The columns you declare at creation become the schema of the table. Cells are text — no type enforcement.

For a Vendors entity, you might start with:

  • vendorId
  • vendorName
  • vendorAccount
  • taxId
  • bankAccount
  • defaultGLAccount
  • currency
  • paymentTerms

You can add more columns later (via the record view's column-add affordance). You can also rename or remove columns — though be careful with renames if existing definitions reference the old name.

How many columns? ​

The honest answer: enough to support the lookups you need, plus a few documentation columns for your own readability.

  • Too few columns and you can't express the lookups your workflows want.
  • Too many columns make uploads slow and the record view cluttered.

For a Vendors entity, 10–15 columns is typical. For a high-cardinality entity like Item Products, 6–8 columns plus a couple of context-narrowing columns is common.

What columns are needed for lookups ​

For each definition that will use this entity, you need:

  • Context columns — the columns that match against document fields. At least one.
  • Mapped columns — the columns whose values get written to document fields.
  • Dropdown columns (for Dropdown Definitions) — the columns that drive dropdown options.

You don't need to know your definitions ahead of time, but the entity's columns need to be rich enough to support the lookups you have in mind. Adding columns later is cheap; reshaping a populated entity is painful.

The discriminator pattern ​

For projects serving multiple subsidiaries / tenants / customers, the discriminator pattern is a strong default:

  • Add a discriminator column (e.g., customerInitials) to every entity that holds tenant-specific data.
  • Put rows for every tenant in the same entity, distinguished by the discriminator value.
  • Use the discriminator as the first Context column in every definition.

For a Vendors entity in a discriminator-pattern project, the columns might be:

  • customerInitials (discriminator)
  • vendorId
  • vendorName
  • vendorAccount
  • (other columns)

The Vendors entity holds vendors for every tenant; the discriminator narrows the lookup to one tenant's data.

This avoids per-tenant entity duplication. Adding a new tenant means adding rows, not creating new entities or new workflows. See Recipes → Serving multiple companies from one project for the worked example.

After creating ​

Once the entity exists, you typically:

  1. Add records — either manually one by one (small entities) or via bulk upload (most cases).
  2. Create definitions inside the entity — lookup rules that reference the columns.
  3. Reference those definitions from workflows — so the lookups actually fire.

The entity by itself does nothing. The definitions you put inside it are what get invoked by workflows.

Editing the entity schema later ​

After creation, the record view lets you:

  • Add columns. New columns start empty for every existing row.
  • Rename columns. Be careful — definitions that reference the old column name will break.
  • Remove columns. Removes the column from every row. Definitions referencing the column will break.

Column changes propagate through the entity immediately. Removed columns don't soft-delete; the data is gone.

Renaming a referenced column breaks definitions

If a definition uses a column as a Context, Mapped, or Dropdown column, renaming that column in the entity makes the definition stop working. The system doesn't automatically rewire references.

Before renaming, search your definitions for references to the column. Or — when in doubt — add the new column, copy data over, update definitions, then remove the old column.
